Model

 MJ6132

 Gross cut capacity

 1500,1600,1800,2200,3000,3200,3800 mm

 Gross cut width

 1,250 mm

 Main saw blade diameter

 300-400 mm

 Bore of main saw blade

 30 mm

 Max height of cut

 80 mm

 Tilting

 45 tilting or90 tilting

 Speed of main saw spindle

 4000 / 6000 rpm

 Main spindle diameter

 30 mm

 Main motor

 220V, 380v, 415v, 3kw, 4kw, 5.5kw

 Scoring saw blade diameter

 120 mm

 Speed of scoring saw blade

 8,000 rpm

 Scoring spindle diameter

 20 mm

 Scoring motor

 1.1 kilowatts

 Gross weight

 850 kgs

 Packing size of the machine body(LxWxH)

 2250 x 1220 x 1240 mm

 Packing size of the sliding table(LxWxH)

 3150 x 430 x 260 mm
